Soundlab G122BN

Power Supply & Consumption

• Power Supply: Passive mechanical support (No electrical power required)

• Power Consumption: N/A

Audio Performance

• Frequency Range: N/A (Mechanical mounting hardware)

• Acoustic Isolation: Weighted cast-iron base equipped with rubber isolation pads on bottom to block desk rumble

Connectivity & Media Playback

• Integrated Media Player: N/A

• Mounting System: Standard 5/8" x 27 tpi threaded stud mount

Controls & Indicators

• Adjustment Elements: Height locking clutch collar, boom extension clamp, T-bar angle locking knob

• Position Adjustment: Vertical height adjustment from 280 mm to 450 mm; adjustable boom reach up to 400 mm

Inputs & Outputs

• Physical Interface: 5/8" threaded mounting adapter

Physical Specifications

• Housing Design: Heavy cast-iron round base with steel upright pole and boom arm (All-black powder-coated finish)

• Base Diameter: 160 mm

• Height Adjustment: 280 mm – 450 mm

• Boom Arm Length: 400 mm

• Weight: 2.70 kg

Accessories Included

• 5/8" to 3/8" Thread Adapter, Microphone Clip
