e-Audio B411A

e-Audio B411A 6.5" In-Wall Speaker (Pair)

System & Power Handling

• System Type: Passive 2-way in-wall installation speaker

• Power Rating: 50 W RMS / 120 W Peak

• Impedance: 8 Ω direct connection

• Operating Voltage: Low-impedance amplifiers (4–8 Ω compatible)

Audio Performance & Transducers

• Low Frequency Driver: 6.5" (165 mm) polycone woofer

• High Frequency Driver: 1" (25 mm) directable titanium dome tweeter

• Frequency Response: 80 – 20,000 Hz

• Sensitivity: 88 dB (1W/1m)

• Dispersion Angle: Wide-angle dispersion with adjustable tweeter targeting

Connectivity & Impedance Matching

• Connection Type: Push-terminal spring connectors

• Impedance Matching: Fixed 8 Ω low-impedance connection

Controls & Adjustment

• Hardware Controls: Integrated electronic crossover network with directional tweeter swivel joint

• Mounting Alignment: Dog-ear wall clamp assembly for secure flush-mount insertion

Enclosure & Hardware

• Frame Material: ABS enclosure frame with paintable white finish

• Front Protection: Flush-fitting perforated steel mesh grille

• Environmental Protection: Indoor architectural mounting

• Application Modes: In-wall stereo, home theater surround sound, and discreet commercial audio installations in offices and reception areas

Physical Specifications

• Cutout Dimensions: 272 x 185 mm

• Dimensions (H x W x D): 305 x 218 x 77 mm

• Weight: 2.58 kg (pair)

Accessories Included

• Flush-Mount Dog-Ear Clamps

• Cutout Template

• Operating Instructions Manual
