System & Power Handling
-
System Type: High-power low-frequency PA woofer driver
-
Power Rating: 200 W RMS / 400 W Peak
-
Impedance: 8 Ω
-
Operating Voltage: Low-impedance power amplifiers
Audio Performance & Transducers
-
Low Frequency Driver: 12" (300 mm) heavy-duty paper cone with accordion cloth edge surround
-
Magnet Weight: 40 oz ferrite magnet
-
Frequency Response: 40 – 4,000 Hz
-
Sensitivity: 94 dB (1W/1m)
Connectivity & Impedance Matching
-
Connection Type: Solder lug terminals
-
Impedance Matching: Fixed 8 Ω direct load
Controls & Adjustment
-
Hardware Controls: None
-
Mounting Alignment: 8-hole perimeter mounting rim
Enclosure & Hardware
-
Chassis Material: Heavy-gauge stamped steel frame
-
Application Modes: Replacement driver for 2-way/3-way PA speakers, sub-bass cabinets, and stage monitors
Physical Specifications
-
Cutout Diameter: 280 mm
-
Dimensions (Diameter x Depth): 308 x 130 mm
-
Weight: 3.6 kg
Accessories Included
-
Technical Parameter Sheet
