Eagle P602HB

Eagle P602HB Horn Speaker

System & Power Handling

• System Type: Weatherproof PA re-entrant horn speaker

• Power Handling: 15 W RMS / 30 W Peak

• Impedance: 8 Ω

• Operating Voltage: 8 Ω low-impedance PA amplifiers

Audio Performance & Transducers

• Driver Type: High-efficiency compression driver

• Frequency Response: 350 – 10,000 Hz

• Sensitivity: 105 dB (1W/1m)

• Dispersion: Conical directional projection

Connectivity & Impedance Matching

• Connection Type: 2-core flying lead wire tail

• Matching: Fixed 8 Ω direct drive

Controls & Adjustment

• Hardware Controls: None

• Mounting Alignment: Steel U-mounting bracket with vertical tilt locking

Enclosure & Hardware

• Flare Material: Grey ABS plastic flare

• Environmental Protection: IP65 weatherproof rating

• Application Modes: Vehicle PAs, outdoor paging, security signaling, and industrial alert systems

Physical Specifications

• Dimensions (H x W x D): 150 x 200 x 230 mm

• Weight: 1.1 kg

Accessories Included

• Adjustable Steel U-Bracket
