Soundlab L060E
System & Power Handling
System Type: High-output 15" low-frequency PA woofer driver
Power Rating: 300 W RMS / 600 W Peak
Impedance: 8 Ω
Operating Voltage: High-power low-impedance PA amplifiers
Audio Performance & Transducers
Low Frequency Driver: 15" (380 mm) treated paper cone with ribbed cloth surround and 2.5" high-temp voice coil
Magnet Weight: 50 oz ferrite magnet
Frequency Response: 35 – 3,500 Hz
Sensitivity: 96 dB (1W/1m)
Connectivity & Impedance Matching
Connection Type: Heavy-duty spring-loaded push terminals
Impedance Matching: Fixed 8 Ω direct load
Controls & Adjustment
Hardware Controls: None
Mounting Alignment: 8-hole heavy chassis rim alignment
Enclosure & Hardware
Chassis Material: Heavy-duty steel basket
Application Modes: Main PA front-of-house subwoofers, full-range 15" cabinets, and stage monitors
Physical Specifications
Cutout Diameter: 355 mm
Dimensions (Diameter x Depth): 385 x 160 mm
Weight: 5.8 kg
Accessories Included
Technical Parameter Sheet
