Eagle P105

Eagle P105 (PA-105) Public Address Amplifier – Technical Specifications & Setup Guide

System & Power Handling

• System Type: Compact public address (PA) mono mixer amplifier

• Amplifier Power: 10 W RMS / 15 W Peak

• Output Modes: High-impedance 100V line output & Low-impedance 4–16 Ω direct speaker output

• Power Supply: 230 V AC, 50 Hz / 12 V DC option (battery/mobile setup capability)

• Power Consumption: Max. 25 W

Audio Performance & Transducers

• Frequency Response: 100 – 15,000 Hz (±3 dB)

• Signal-to-Noise Ratio (S/N Ratio): Mic > 60 dB, Aux > 70 dB

• Total Harmonic Distortion (THD): < 1.0% @ rated output power (1 kHz)

• Line/Speaker Outputs: Screw terminal strip for 100V line, 4–16 Ω, and COM (common ground)

Connectivity & Input Options

• Microphone Input: 1 x 6.3 mm (1/4") unbalanced Jack input (front panel) with dedicated gain control

• Auxiliary Line Input: 1 x Stereo RCA pair / 6.3 mm (1/4") Jack line input for external media playback (CD, tuner, media player)

• Priority Muting: Override / voice-activated priority function on Mic 1 input for announcements over music playback

Controls & Indicators

• Control Elements: Front-panel Master Volume control, Mic 1 Level control, Aux Line Level control, Tone Control (Bass/Treble tilt)

• Power Switch: Rocker ON/OFF switch with front-panel LED indicator

• Status Indicators: Power status LED indicator

Enclosure & Hardware

• Cabinet Material: Steel chassis enclosure (black finish) with rubber feet for tabletop positioning

• Front Panel: Durable aluminum front fascia with rotary potentiometers

• Heat Management: Convection cooling with rear/side passive airflow vents

• Application Modes: Desktop mono PA amplifier for small commercial installations, offices, waiting rooms, small shops, and mobile 12V vehicle PA systems

Physical Specifications

• Dimensions (W x D x H): 240 x 220 x 78 mm (9.4" x 8.7" x 3.1")

• Weight: 2.8 kg (6.2 lbs)

Accessories Included

• Mains Power Cable (Fused)

• Terminal Block Connectors

• Operating Instructions Manual
