Eagle P111CC

Eagle P111CC Mobile Public Address Amplifier – Technical Specifications & Setup Guide

System & Power Handling

• System Type: Compact mobile public address (PA) mono amplifier with built-in siren/horn generator

• Amplifier Power: 45 W RMS / 60 W Peak

• Output Modes: Low-impedance 4–16 Ω direct speaker output

• Power Supply: 12 V DC (11–15 V DC operational range, vehicle/battery power)

• Power Consumption: Max. 60 W (at full output)

Audio Performance & Transducers

• Frequency Response: 80 – 15,000 Hz (±3 dB)

• Signal-to-Noise Ratio (S/N Ratio): Mic > 65 dB, Aux > 75 dB

• Total Harmonic Distortion (THD): < 1.0% @ rated output power (1 kHz)

• Speaker Outputs: Heavy-duty screw/push terminal block for 4–16 Ω low-impedance connection

Connectivity & Input Options

• Microphone Inputs: 2 x 6.3 mm (1/4") Jack inputs with individual gain controls (Mic 1 front panel, Mic 2 rear panel)

• Auxiliary Line Input: 1 x Stereo RCA pair / 3.5 mm mini-jack line input for background audio devices

• Alert Signal Generator: Integrated switchable Siren / Fog / Horn sound generator for vehicle signaling and public announcements

Controls & Indicators

• Control Elements: Front-panel Master Volume control, Mic 1 & Mic 2 Volume knobs, Aux Level control, Siren/Horn selector switch

• Power Switch: Front-panel rocker switch with 12V DC reverse polarity protection

• Status Indicators: Power status LED indicator

Enclosure & Hardware

• Cabinet Material: Compact heavy-duty steel chassis (black finish)

• Mounting Hardware: Under-dash / vehicle mounting bracket and fixing kit included

• Heat Management: Convection cooling via passive side-vented chassis airflow

• Application Modes: High-output mobile vehicle PA (cars, commercial vans, security patrol vehicles, parade floats, mobile announcement units, marine vessels)

Physical Specifications

• Dimensions (W x D x H): 180 x 150 x 60 mm (7.1" x 5.9" x 2.4")

• Weight: 1.35 kg (3.0 lbs)

Accessories Included

• 12 V DC Fused Power Cable with Bare-Wire / Cigarette Lighter Leads

• Vehicle Under-Dash Mounting Bracket & Fixing Screws

• Operating Instructions Manual
