Eagle P110

Eagle P110 (PA-110) Public Address Amplifier – Technical Specifications & Setup Guide

System & Power Handling

• System Type: Commercial public address (PA) mono mixer amplifier

• Amplifier Power: 120 W RMS / 180 W Peak

• Output Modes: High-impedance 70V / 100V line outputs & Low-impedance 4–16 Ω direct speaker output

• Power Supply: 230 V AC, 50 Hz / 24 V DC backup power terminals

• Power Consumption: Max. 200 W

Audio Performance & Transducers

• Frequency Response: 60 – 18,000 Hz (±3 dB)

• Signal-to-Noise Ratio (S/N Ratio): Mic > 70 dB, Line/Aux > 80 dB

• Total Harmonic Distortion (THD): < 0.5% @ rated output power (1 kHz)

• Line/Speaker Outputs: Heavy-duty screw terminal barrier strip for 70V, 100V, 4–16 Ω, and COM (common)

Connectivity & Input Options

• Microphone Inputs: 3 x XLR / 6.3 mm (1/4") Jack inputs with individual level controls (Mic 1 front panel with priority override option; Mic 2–3 rear panel)

• Auxiliary Line Inputs: 2 x Stereo RCA pair inputs (Aux 1 / Aux 2) for background audio playback

• Line Output: 1 x Stereo RCA / 6.3 mm Jack line output (Pre-Amp Out) for connection to booster amplifiers

• Priority Muting: Adjustable VOX priority ducking on Mic 1 to override background audio sources during emergency announcements or paging

Controls & Indicators

• Control Elements: Front-panel Master Volume control, Mic 1–3 individual Level controls, Aux 1–2 Level controls, 2-Band Equalizer (Bass & Treble controls)

• Power Switch: Front-panel rocker switch

• Status Indicators: Power status LED, 6-segment LED VU output level meter, Protection / Fault LED indicator

Enclosure & Hardware

• Cabinet Material: Steel chassis enclosure (black finish) with removable 2U rack-mount brackets

• Front Panel: Durable black anodized aluminum front panel with rotary knobs

• Heat Management: Internal heatsink cooling with temperature-controlled low-noise forced cooling fan

• Application Modes: Mid-to-large commercial installations, multi-zone paging systems, supermarkets, schools, factories, and places of worship

Physical Specifications

• Dimensions (W x D x H): 483 x 320 x 88 mm (19.0" x 12.6" x 3.5") – 2U 19" Rackmount

• Weight: 7.2 kg (15.9 lbs)

Accessories Included

• Mains Power Cable (IEC)

• 19" Rack-Mount Mounting Brackets & Hardware

• Terminal Strip Cover & Screws

• Operating Instructions Manual
