System & Power Handling
-
System Type: Compact full-range chassis speaker unit
-
Power Rating: 30 W RMS / 60 W Peak
-
Impedance: 8 Ω
-
Operating Voltage: Low-impedance amplifiers
Audio Performance & Transducers
-
Full-Range Driver: 4" (100 mm) paper cone transducer with rubber surround
-
Frequency Response: 100 – 15,000 Hz
-
Sensitivity: 87 dB (1W/1m)
Connectivity & Impedance Matching
-
Connection Type: Solder lug tabs
-
Impedance Matching: Fixed 8 Ω connection
Controls & Adjustment
-
Hardware Controls: None
-
Mounting Alignment: 4-hole mounting flange
Enclosure & Hardware
-
Chassis Material: Stamped steel frame
-
Application Modes: Small intercoms, background music cabinets, and replacement ceiling/wall speaker drivers
Physical Specifications
-
Cutout Diameter: 95 mm
-
Dimensions (Diameter x Depth): 102 x 48 mm
-
Weight: 0.48 kg
Accessories Included
-
Specification Sheet
