Soundlab P115CP

Soundlab P115CP – Technical Specifications & Setup Guide

System & Power Handling

• System Type: 2-way passive bass-reflex PA speaker enclosure

• Power Rating: 200 W RMS

• Program Power: 400 W Peak

• Nominal Impedance: 8 Ω

Audio Performance & Transducers

• Low Frequency Driver: 15" (380 mm) heavy-duty woofer

• High Frequency Driver: High-frequency piezo horn tweeter

• Frequency Range: 45 – 20,000 Hz

• Sensitivity: 96 dB (1W/1m)

• Max SPL: 119 dB

• Crossover Frequency: Internal 2-way passive crossover network

Connectivity & Signal Routing

• Inputs: 2 x 6.3 mm (1/4") TS jack sockets, 2 x Speaker-compatible sockets (parallel wiring)

• Signal Link: Parallel loop-through connection for daisy-chaining additional passive speakers

Enclosure & Hardware

• Cabinet Material: High-density wooden enclosure wrapped in durable black acoustic carpet

• Front Protection: Heavy-duty full-face black steel mesh grille

• Mounting / Suspension: Integrated Ø 35 mm top-hat pole socket for tripod mounting

• Handles: 2 x Side-mounted recessed carrying handles

• Corner Protection: High-impact plastic corner protectors

Physical Specifications

• Dimensions (W x D x H): 480 x 380 x 680 mm (18.9" x 15.0" x 26.8")

• Weight: 15.2 kg (33.5 lbs)

Accessories Included

• Operating Instructions Sheet
