Soundlab P115CPA

Soundlab P115CPA – Technical Specifications & Setup Guide

System & Power Handling

• System Type: 2-way active bass-reflex PA speaker enclosure

• Power Output: 200 W RMS / 400 W Peak (built-in power amplifier)

• Frequency Response: 45 – 20,000 Hz

• Max SPL: 119 dB

Audio Performance & Transducers

• Low Frequency Driver: 15" (380 mm) heavy-duty woofer

• High Frequency Driver: High-frequency piezo horn tweeter

• Equalization: 2-band EQ (Bass & Treble rotary controls)

• Protection Circuitry: Integrated peak limiter and thermal overload protection

Connectivity & Signal Routing

• Microphone Input: 1 x 6.3 mm (1/4") TS jack / XLR input with independent Gain control

• Line Input: 1 x Stereo RCA pair / 6.3 mm (1/4") Jack input with independent Volume control

• Line Output: 1 x 6.3 mm (1/4") Jack / XLR line-out link connector (for daisy-chaining active speakers)

• Speaker Output: 1 x Speaker-compatible socket (8 Ω output for powering a passive companion speaker, e.g., P115CP)

Controls & Indicators

• Control Elements: Master Volume, Mic Volume, Line Volume, Bass control, Treble control

• Indicators: Power status LED, Clip/Limit indicator LED

Physical Specifications

• Cabinet Material: High-density wooden enclosure wrapped in durable black acoustic carpet

• Front Protection: Heavy-duty full-face black steel mesh grille

• Mounting / Suspension: Integrated Ø 35 mm top-hat pole socket for tripod mounting

• Handles: 2 x Side-mounted recessed carrying handles

• Corner Protection: High-impact plastic corner protectors

• Dimensions (W x D x H): 480 x 380 x 680 mm (18.9" x 15.0" x 26.8")

• Weight: 17.5 kg (38.6 lbs)

Accessories Included

• Mains Power Cable

• Operating Instructions Sheet
