Behringer XENYX 802S

€125.00 incl. VAT
Out of stock
Interested in this product?
Call us

Overview

Behringer XENYX802S

The Behringer Xenyx 802S is an affordable and powerful tool for beginning content creators and professionals on the go. 8 channels of crisp, award-winning sound with ample audial control allow podcasters, gamers, and live streamers to easily direct audio for efficient creation applications. Similarly, its USB compatibility enables user to access the 802S’ features from their computer, mobile phone, or other smart device. With a versatile I/O including RCA, 1/4-inch, and XLR connections, there’s virtually no audio scenario the 802S can’t handle — and it’s compact enough to fit on your desk, stage table, or even in your backpack! Sweetwater content creators are always on the go. When it comes down to mixing in a pinch, they always turn to the Xenyx 802S.



Behringer XENYX 802S – Technical Specifications & Setup Guide

Power Supply & Consumption

  • Power Supply: 100–240 V AC, 50/60 Hz (via included external 18 V DC, 1.0 A power adapter)

  • Power Connection: DC power input socket on rear panel

Audio Performance

  • Frequency Response: 10 Hz – 150 kHz (-1 dB)

  • S/N Ratio: 110 dB A-weighted (0 dBu In @ +22 dB gain)

  • THD+N: 0.005% A-weighted

  • Channel Equalizer: 3-band EQ per channel (High: 12 kHz ±15 dB, Mid: 2.5 kHz ±15 dB, Low: 80 Hz ±15 dB)

Connectivity & Streaming

  • USB Interface: Type-B USB Audio (Stereo In/Out, 16-bit / 48 kHz class-compliant)

  • Audio Channels: 2 Mono mic/line channels (Ch 1 & 2), 2 Stereo line channels (Ch 3/4 & 5/6)

  • Phantom Power: +48V phantom power (global switch with LED indicator for condenser mics)

Controls & Indicators

  • Control Elements: Channels 1 & 2 Gain controls, 3-band EQ knobs, FX Send knobs per channel, Pan/Bal controls, Level knobs per channel, Main Mix volume knob, FX Send master knob, Phones/Control Room volume knob, Stream To Mix / Stream To Monitor buttons

  • Indicators: Power LED, +48V Phantom Power LED, Main Mix level LED meters, Clip LEDs (Ch 1 & 2)

Inputs & Outputs

  • Inputs:

    • Mic Inputs: 2 x XLR (balanced, Ch 1 & 2)

    • Line Inputs: 2 x 6.35 mm (1/4") TRS jacks (Ch 1 & 2 Mono), 4 x 6.35 mm (1/4") TRS jacks (Ch 3/4 Stereo, Ch 5/6 Stereo)

    • Stream Inputs: 1 x RCA Stereo pair (or via USB audio)

  • Outputs:

    • Main Output: 2 x 6.35 mm (1/4") TRS jacks (L/R)

    • Control Room Output: 2 x 6.35 mm (1/4") TRS jacks (L/R)

    • FX Send Output: 1 x 6.35 mm (1/4") TRS jack

    • Headphones Output: 1 x 6.35 mm (1/4") TRS stereo jack

    • Stream Output: 1 x RCA Stereo pair (or via USB audio)

Physical Specifications

  • Housing Design: Ultra-compact desktop console chassis

  • Dimensions (W x D x H): 189 x 220 x 47 mm (7.4 x 8.7 x 1.9")

  • Weight: 1.6 kg (3.5 lbs)

Accessories Included

  • External Power Supply, USB Cable, Quick Start Guide
