Overview

Behringer X2222USB (ZB601)

The Behringer XENYX2222USB Mixer has 8 XENYX mic channels with inserts, dedicated compressors, 3 band EQ with semi-parametric mids. and three Aux Sends. How about eight XENYX mic channels with inserts, dedicated compressors, 3 band EQ with semi-parametric mids. and three Aux Sends? You get all that with the X2222USB, plus four stereo line-level channels, two convenient mix subgroups and on-board 24 bit digital FX processing, with dual user-addressable parameter controls. All this and more enclosed in a rack-ready, roadworthy steel chassis.

Behringer XENYX X2222USB – Technical Specifications & Setup Guide

Power Supply & Consumption

  • Power Supply: 100–240 V AC, 50/60 Hz (auto-ranging internal switch-mode power supply)

  • Power Consumption: 50 W

  • Power Connection: Standard IEC C14 power inlet with physical power switch

Audio Performance

  • Frequency Response: 10 Hz – 150 kHz (-1 dB)

  • S/N Ratio: 110 dB A-weighted (0 dBu In @ +22 dB gain)

  • THD+N: 0.0058% A-weighted

  • Channel Equalizer:

    • Mono Channels: 3-band semi-parametric EQ with sweepable mid-range (High: 12 kHz, Mid: 100 Hz–8 kHz, Low: 80 Hz)

    • Stereo Channels: 4-band fixed EQ (High: 12 kHz, High-Mid: 3 kHz, Low-Mid: 500 Hz, Low: 80 Hz)

  • FX Unit: 24-bit Klark Teknik multi-effects processor with LCD display, dual parameters, Tap function, and storeable user parameter settings

  • Compressors: 8 studio-grade "one-knob" analog compressors with dynamic LED metering (Channels 1–8)

Connectivity & Streaming

  • USB Interface: Type-B USB Audio (Stereo In/Out, 16-bit / 48 kHz class-compliant)

  • Wireless Option: "Wireless-ready" USB port for Behringer ULM digital wireless microphone systems

  • Audio Channels: 8 Mono mic/line channels, 4 Stereo line channels

  • Phantom Power: +48V global phantom power switch with LED indicator

Controls & Indicators

  • Control Elements: 60 mm logarithmic-taper faders per channel and master/subgroups, Gain controls, 1-knob Compressors (Ch 1–8), 3-band/4-band EQs, 3 AUX sends per channel (1 Pre-fader monitoring, 1 Pre/Post switchable, 1 Post-fader/FX), Mute, Solo/PFL, Subgroup 1-2, Subgroup 3-4, and Main routing switches

  • Indicators: Dual 12-segment LED peak meters, Clip and Mute LEDs per channel, Solo/PFL active LED, +48V LED, Power LED

Inputs & Outputs

  • Inputs:

    • Mic Inputs: 8 x XLR (balanced, Ch 1–8)

    • Line Inputs: 8 x 6.35 mm (1/4") TRS jacks (Mono) + 4 x Stereo pairs (6.35 mm TRS)

    • Channel Inserts: 8 x 6.35 mm (1/4") TRS jacks (Channels 1–8)

    • 2-Track / Tape In: 1 x RCA Stereo pair

  • Outputs:

    • Main Output: 2 x XLR (balanced) and 2 x 6.35 mm (1/4") TRS jacks

    • Control Room Output: 2 x 6.35 mm (1/4") TRS jacks

    • Subgroup Outputs: 4 x 6.35 mm (1/4") TRS jacks (Sub 1, 2, 3, 4)

    • AUX Sends: 3 x 6.35 mm (1/4") TRS jacks

    • AUX Returns: 2 x Stereo pairs (4 x 6.35 mm TRS jacks)

    • Headphones Output: 1 x 6.35 mm (1/4") TRS stereo jack

    • 2-Track / Tape Out: 1 x RCA Stereo pair

Physical Specifications

  • Housing Design: Metal console chassis with included 19" rack-mount ears

  • Dimensions (W x D x H): 430 x 370 x 90 mm (16.9" x 14.6" x 3.5")

  • Weight: 4.8 kg (10.6 lbs)

Accessories Included

  • Power Cable (IEC), 19" Rack-Mount Brackets, USB Cable, Quick Start Guide
