Eagle P107

Eagle P107 (PA-107) Public Address Amplifier – Technical Specifications & Setup Guide

System & Power Handling

• System Type: Compact public address (PA) mono mixer amplifier

• Amplifier Power: 30 W RMS / 45 W Peak

• Output Modes: High-impedance 70V / 100V line outputs & Low-impedance 4–16 Ω direct speaker output

• Power Supply: 230 V AC, 50 Hz / 12 V DC option (battery/mobile setup capability)

• Power Consumption: Max. 60 W

Audio Performance & Transducers

• Frequency Response: 80 – 16,000 Hz (±3 dB)

• Signal-to-Noise Ratio (S/N Ratio): Mic > 65 dB, Aux > 75 dB

• Total Harmonic Distortion (THD): < 1.0% @ rated output power (1 kHz)

• Line/Speaker Outputs: Heavy-duty barrier screw terminal strip for 70V, 100V, 4–16 Ω, and COM (common)

Connectivity & Input Options

• Microphone Inputs: 2 x 6.3 mm (1/4") unbalanced Jack inputs with individual gain controls (Mic 1 front panel, Mic 2 rear panel)

• Auxiliary Line Input: 1 x Stereo RCA pair line input for background music devices (CD/MP3 players, tuners)

• Priority Muting: Built-in voice-activated priority override on Mic 1 input (automatically ducking Aux audio during announcements)

Controls & Indicators

• Control Elements: Front-panel Master Volume control, Mic 1 & Mic 2 Level controls, Aux Level control, 2-Band Tone Controls (Bass & Treble)

• Power Switch: Heavy-duty rocker switch with front-panel LED indicator

• Status Indicators: Power status LED indicator, 4-segment LED output level meter

Enclosure & Hardware

• Cabinet Material: Rigid steel chassis enclosure (black finish) with rubber feet for desktop placement

• Front Panel: Durable aluminum front fascia with rotary control knobs

• Heat Management: Convection cooling with passive side/rear ventilation slots

• Application Modes: Desktop mono PA amplifier for small-to-medium commercial installations, retail spaces, cafes, schools, places of worship, and mobile 12V vehicle PA systems

Physical Specifications

• Dimensions (W x D x H): 280 x 240 x 88 mm (11.0" x 9.4" x 3.5")

• Weight: 3.6 kg (7.9 lbs)

Accessories Included

• Fused Mains Power Cable

• Terminal Strip Cover & Screws

• Operating Instructions Manual
