Eagle P108

Eagle P108 (PA-108) Public Address Amplifier – Technical Specifications & Setup Guide

System & Power Handling

• System Type: Compact public address (PA) mono mixer amplifier

• Amplifier Power: 60 W RMS / 90 W Peak

• Output Modes: High-impedance 70V / 100V line outputs & Low-impedance 4–16 Ω direct speaker output

• Power Supply: 230 V AC, 50 Hz / 12 V DC option (battery/mobile setup capability)

• Power Consumption: Max. 100 W

Audio Performance & Transducers

• Frequency Response: 70 – 18,000 Hz (±3 dB)

• Signal-to-Noise Ratio (S/N Ratio): Mic > 65 dB, Aux > 75 dB

• Total Harmonic Distortion (THD): < 1.0% @ rated output power (1 kHz)

• Line/Speaker Outputs: Heavy-duty barrier screw terminal strip for 70V, 100V, 4–16 Ω, and COM (common)

Connectivity & Input Options

• Microphone Inputs: 2 x 6.3 mm (1/4") Jack inputs with individual volume controls (Mic 1 front panel, Mic 2 rear panel)

• Auxiliary Line Inputs: 2 x Stereo RCA pair line inputs (Aux 1 / Aux 2) for background music devices

• Priority Muting: Voice-activated priority override on Mic 1 input for automatic ducking of background music during paging

Controls & Indicators

• Control Elements: Front-panel Master Volume control, Mic 1 & Mic 2 Volume controls, Aux 1 & Aux 2 Level controls, 2-Band Equalizer (Bass & Treble controls)

• Power Switch: Front-panel rocker switch with illuminated power indicator

• Status Indicators: Power status LED indicator, 5-segment LED VU output level meter

Enclosure & Hardware

• Cabinet Material: Steel chassis enclosure (black finish) with rubber feet for tabletop or shelf installation

• Front Panel: Brushed aluminum front fascia with rotary potentiometers

• Heat Management: Convection cooling with side and top passive ventilation slots

• Application Modes: Commercial PA system for medium-sized retail environments, offices, restaurants, warehouses, school halls, and 12V mobile announcement setups

Physical Specifications

• Dimensions (W x D x H): 320 x 250 x 88 mm (12.6" x 9.8" x 3.5")

• Weight: 4.8 kg (10.6 lbs)

Accessories Included

• Mains Power Cable

• DC Power Connector Lead

• Terminal Barrier Strip Cover

• Operating Instructions Manual
