Behringer XENYX 302USB

€89.00 incl. VAT
In stock
Interested in this product?
Call us

Overview

Behringer 302USB (ZB702)

The new XENYX 302USB is ideally suited for a small home studio or the on the go recording enthusiast. At approximately 4" long and 5" wide (117x135 mm), the XENYX 302USB respects your desk space, while providing an XLR and 1/4" combination socket, stereo USB/Line channel plus a dedicated 2 Track input.

Behringer XENYX 302USB Premium 5-Input Mixer – Technical Specifications

Power Supply & Consumption

  • Power Supply: 5 V DC, 500 mA (via USB 2.0 connection or included external USB power adapter)

  • Power Consumption: 0.9 W

  • Mains Connection: Micro-USB port for power and data link

Audio Performance

  • Frequency Range: 10 – 160,000 Hz (+0 dB / -1 dB)

  • S/N Ratio: 110 dB A-weighted (0 dBu In @ +22 dB gain)

  • THD+N: 0.005% A-weighted

  • Equivalent Input Noise (Mic): -130 dB (150 Ω source)

  • Channel Equalizer: 2-band graphic EQ (80 Hz Low & 12 kHz High, ±15 dB) on channel strips

  • Phantom Power: +15 V DC phantom power (switchable for condenser mic input)

Connectivity & Media Playback

  • Integrated Audio Interface: Stereo USB audio interface (16-bit, 48 kHz sampling rate) for direct recording to PC/Mac

  • USB Compatibility: Plug-and-play USB 2.0 compliant (class-compliant, no driver installation required)

  • Audio Routing: Dedicated USB/Line switchable routing to Main Mix or Phones/Headset output

Controls & Indicators

  • Control Elements: Mic Gain knob, Mic 2-band EQ (Low/High), Line 2-band EQ (Low/High), Mic Level knob, Line Level knob, USB/2-Track Level knob, Main Mix Level knob, USB/Line Assign switches, Phantom Power switch

  • Indicators: Power status LED, Clip LED indicator for Mic channel, 2-segment LED output meter

Inputs & Outputs

  • Inputs:

    • Microphone Input: 1 x Combo XLR / 6.35 mm TRS jack (balanced, front/top panel)

    • Headset Mic Input: 1 x 3.5 mm TRS mini-jack (mono, front panel)

    • Line Inputs: 1 x Stereo RCA pair (Line In)

    • 2-Track / USB Input: 1 x Stereo RCA pair (2-Track In)

  • Outputs:

    • Main Output: 1 x Stereo RCA pair (Main Mix Out)

    • Headphones Output: 1 x 3.5 mm TRS mini-jack (stereo, front panel)

Physical Specifications

  • Housing Design: Ultra-compact desktop metal enclosure with impact-resistant side bumpers

  • Rack Mounting: N/A (Desktop ultra-compact unit)

  • Dimensions (W x D x H): 114 x 136 x 46 mm

  • Weight: 0.38 kg

Accessories Included

  • USB Power/Data Cable, External USB Power Adapter, User Manual
