E-Audio A097M

E-Audio A097M – Technical Specifications & Setup Guide

Power Supply & Amplification

• Power Supply: 100–240 V AC, 50/60 Hz (external 12 V – 15 V DC power adapter included)

• Power Output: 2 x 15 W RMS @ 4 Ω (Class-D amplification)

• Peak Power: 2 x 30 W Max

• Minimum Load Impedance: 4 Ω per channel

Audio Performance & Wireless Specifications

• Amplifier Class: Class-D Digital Amplifier

• Bluetooth Version: 4.0 / 5.0 (Class 2)

• Bluetooth Range: Up to 10 m (33 ft) line-of-sight

• Frequency Response: 20 – 20,000 Hz

• Signal-to-Noise Ratio (S/N): >80 dB

• Total Harmonic Distortion (THD): <0.1% @ 1 kHz

Connectivity & Signal Routing

• Wireless Connection: Bluetooth A2DP audio streaming

• Speaker Connections: Screw terminals / spring clip terminals (L/R output)

• Auxiliary Input: 3.5 mm stereo AUX input jack

Controls & Indicators

• Control Elements: Rotary Volume / Power knob, Bluetooth pairing button

• Status Indicators: Dual-color LED indicator (Power status / Bluetooth pairing status)

Inputs & Outputs

• Audio Inputs: Bluetooth wireless, 1 x 3.5 mm Aux jack

• Speaker Outputs: 4-pin screw terminal block (Left +, Left -, Right +, Right -)

• Power Input: 1 x DC Barrel Jack (12 V DC)

Physical Specifications

• Housing Design: Ultra-compact, low-profile metal/ABS enclosure for wall-mounting or surface placement

• Dimensions (W x D x H): 120 x 85 x 35 mm (4.7" x 3.3" x 1.4")

• Weight: 220 g (0.48 lbs)

Accessories Included

• 12 V DC Power Supply Adapter

• Screw Terminal Block Connector

• Mounting Brackets & Screws

• Operating Instructions Manual
